Fractionation Procedure
Physical length classification instruments employ dual banks of precision-spaced fine steel combs to separate unspun staple bundles into sorted length arrays by mechanical manual withdrawal. Known formally across standard test procedures as the comb sorter method, this primary laboratory technique isolates individual fiber groupings from a conditioned test specimen to construct a cumulative length-frequency diagram. Operating across flax lines, the mechanism measures the percentage distribution of long fibers against short remnants left behind during scutching, hackling and combing stages.
The mechanical sorter handles fibers by clamping, pulling and redepositing aligned strands across parallel pins until all constituent lengths lie sorted on a contrasting velvet sorting board. The procedure terminates when the sample array is transferred to the evaluation pad for geometric profiling or weight apportionment, establishing base length metrics prior to roving formulation.
Mechanical Execution
Laboratory operators prepare a square specimen of degummed or hackled flax, conditioning the mass under standard temperature and relative humidity parameters to eliminate static adhesion. Tweezers draw small tufts through the primary comb bank, squaring the base ends against an initial comb margin. Successive combs drop down one by one, exposing the tip ends of the longest bast fibers, which the technician withdraws using wide-jaw gripping forceps.
These extracted bundles are redeposited into the secondary bank, creating an orderly sequence running from the longest fiber cluster down to short fragments below ten millimeters. Dropping combs systematically prevents fiber breakage during extraction, ensuring that naturally occurring fiber lengths are documented rather than mechanical fractures induced by manual pulling. The technician transfers each sorted sub-group onto a black velvet board, pressing the fibers flat with a wire-wound roller to produce an aligned trace line.
Array Evaluation
Generating a cumulative frequency curve from the completed sorting array yields the effective staple length alongside the percentage of short fiber content. Bast fiber processors utilize these extracted length values to adjust the roller drafting ratch on wet spinning frames, matching drafting zone gaps to the longest quartile of the combed flax population. A high proportion of fragments below fifteen millimeters recorded in the test report flags excessive mechanical damage during hackling, warning spinning managers that roving will display thick-and-thin irregularities and high slub rates.
Mill intake laboratories run this manual separation alongside automated airflow measurement to verify that incoming fiber lots match purchasing contracts. Fiber lots failing the agreed length profile face immediate downgrade or re-routing into blended rotor lines. Test documentation generated by the comb sorter provides the legal benchmark in commercial settlement arbitrations, overriding high-speed optical measurements whenever fiber clinging generates disputed length distributions.
