Vertical Displacement
Vertical travel distance of the harness frames during the shedding phase dictates the maximum vertical clearance created for the weft insertion element. Mechanical adjustments set the heddle stroke length through crank linkages, side levers or electronic dobby programs inside the loom chassis. Bast fibres demonstrate minimal elasticity compared to cotton or synthetic filaments, making vertical shed height exceptionally critical during weaving.
Excessive stroke lengths overstretch warp ends, exceeding the ultimate tensile limit of wet-spun linen and triggering high end-breakage rates.
Shed Balancing
Loom tuners position heddle frames progressively, increasing stroke travel on back harnesses to maintain a clean shed angle from front to rear. The forward harness, closest to the reed, operates with the shortest stroke, while each subsequent harness requires a greater heddle stroke length to clear the insertion path. Incorrect mechanical adjustments produce trailing yarns that catch the rapier head or deflect the air-jet trajectory, resulting in broken picks or mechanical warp jams.
Technicians record stroke heights on loom specification cards, measuring clearance from the bottom shed line to the top wire eyelet.
Weaving Performance
Proper stroke dimensioning limits friction between adjacent linen fibres, particularly on high-density warp counts containing natural slubs or irregular diameter variations. If the shed opening is set too shallow, coarse yarn irregularities snag during harness crossings, pulling heddle eyes out of alignment and scarring adjacent warp filaments. If the opening travel is set too deep, cyclic fatigue breaks individual linen ends behind the drop wires, dropping overall machine running efficiency.
Modern mills monitor harness frame acceleration and lift stroke to minimize yarn strain while retaining reliable pick clearance.
